Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 20 |
Edges per primitive translational unit | 44 |
Transitivity (vertex,edge) | (4,5) |
Vertex degrees | {8,4,3,8} |
Vertex coordination sequence | [(8, 40, 124, 256, 440, 672, 956, 1288, 1672, 2104), (4, 12, 38, 124, 270, 464, 706, 1000, 1342, 1736), (3, 7, 15, 71, 206, 387, 614, 893, 1220, 1599), (8, 4, 24, 102, 256, 448, 692, 984, 1328, 1720)] |
Wells’ vertex symbol | [6^14.8^12.12^2, 3^2.4.6^3, 3^2.4, 3^8.4^8.5^8.6^4] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 0, 1, 1, 2, 0, 1, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 3, 13, 0, 0, 0, 4, 11, 0, -1, 1, 4, 13, 0, -1, 1, 4, 14, 0, 0, 0, 5, 11, 1, 0, 0, 5, 12, 1, 0, 0, 5, 15, 0, 0, 0, 6, 11, 1, -1, 1, 6, 14, 1, 0, 0, 6, 15, 0, -1, 1, 7, 16, 0, 0, 0, 7, 17, 0, 0, 0, 7, 18, 0, 0, 0, 8, 16, 0, -1, 1, 8, 18, 0, -1, 1, 8, 19, 0, 0, 0, 9, 16, 1, 0, 0, 9, 17, 1, 0, 0, 9, 20, 0, 0, 0, 10, 16, 1, -1, 1, 10, 19, 1, 0, 0, 10, 20, 0, -1, 1, 11, 12, 0, 0, 0, 11, 13, 0, 0, 0, 11, 14, 0, 1, -1, 11, 15, -1, 0, 0, 16, 17, 0, 0, 0, 16, 18, 0, 0, 0, 16, 19, 0, 1, -1, 16, 20, -1, 0, 0) |
Spacegroup: I41/amd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.55075 | 3.55075 | 9.7852 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.375 |
0.15 | 0.6 | 0.125 |
0 | 0.65 | 0.125 |
0 | 0.75 | 0.125 |
Edge end points:
Spacegroup: I41/amd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.50666 | 2.50666 | 1.4329 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.375 |
0.24998 | 0.50002 | 0.125 |
0 | 0.50005 | 0.30872 |
0 | 0.75 | 0.125 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1872 | *2244 | (4,5,2) | {8,4,3,8} | {10.10.10.10.10.10.10.10}{10.3.3... |
