Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 60 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {7,4,4} |
Vertex coordination sequence | [(7, 28, 85, 187, 324, 492, 686, 914, 1170, 1466), (4, 10, 31, 96, 212, 362, 551, 749, 1001, 1253), (4, 10, 31, 95, 213, 362, 551, 749, 1001, 1253)] |
Wells’ vertex symbol | [3.4^6.5^2.6^6.7^5.8, 3.4^3.5^2, 3.4^3.5^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 1, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 2, 11, 0, 0, 0, 2, 12, 0, 0, 0, 3, 4, 0, 0, 1, 3, 5, 0, 1, 0, 3, 12, 0, 0, 0, 3, 12, 1, 0, 0, 3, 13, 0, 0, 0, 3, 14, 0, 0, 0, 4, 5, 1, 0, -1, 4, 8, 1, 0, 0, 4, 8, 2, -1, -1, 4, 15, 0, 0, 0, 4, 16, 0, 0, 0, 5, 11, 0, 0, 0, 5, 11, 1, -1, -1, 5, 17, 0, 0, 0, 5, 18, 0, 0, 0, 6, 7, 0, 0, 0, 6, 9, 1, -1, 0, 6, 16, 0, 0, 0, 7, 10, 1, -1, 0, 7, 17, 0, 0, 0, 8, 11, 0, 0, -1, 8, 12, -1, 1, 0, 8, 19, 0, 0, 0, 8, 20, 0, 0, 0, 9, 10, 0, 0, 0, 9, 20, 0, 0, 0, 10, 21, 0, 0, 0, 11, 12, -1, 0, 1, 11, 21, 0, 0, 0, 11, 22, 0, 0, 0, 12, 23, 0, 0, 0, 12, 24, 0, 0, 0, 13, 14, 0, 0, 0, 13, 18, 0, 1, 0, 13, 23, 0, 0, 1, 14, 15, 0, 0, 1, 14, 24, 0, 0, 1, 15, 16, 0, 0, 0, 15, 19, 1, -1, 0, 16, 20, 1, -1, 0, 17, 18, 0, 0, 0, 17, 21, 1, -1, 0, 18, 22, 1, -1, 0, 19, 20, 0, 0, 0, 19, 24, -1, 1, 0, 21, 22, 0, 0, 0, 22, 23, -1, 0, 1, 23, 24, 0, 0, 0) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.71862 | 3.71862 | 4.42819 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.59174 | 0.14706 | 0.0625 |
0.19806 | 0.69401 | 0.1125 |
0.1843 | 0.72342 | 0.0125 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.87731 | 1.87731 | 3.08932 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.50296 | 0.27091 | 0.0482 |
0.12608 | 0.21361 | 0.05007 |
0.34187 | 0.54748 | 0.14388 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2398 | *22222 | (2,7,6) | {4,7} | {4.4.3.4}{3.4.4.4.4.4.4} |
