Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 32 |
Edges per primitive translational unit | 60 |
Transitivity (vertex,edge) | (2,3) |
Vertex degrees | {6,3} |
Vertex coordination sequence | [(6, 15, 12, 21, 43, 39, 66, 129, 105, 126), (3, 9, 18, 21, 24, 50, 66, 74, 144, 154)] |
Wells’ vertex symbol | [3^3.5^6.6^3.8^3, 5^3] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 1, 7, 0, 0, 0, 2, 3, 0, 0, 0, 2, 4, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 4, 0, 0, 0, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 3, 13, 0, 0, 0, 4, 14, 0, 0, 0, 4, 15, 0, 0, 0, 4, 16, 0, 0, 0, 5, 17, 0, 0, 0, 5, 18, 0, 0, 0, 6, 19, 0, 0, 0, 6, 20, 0, 0, 0, 7, 21, 0, 0, 0, 7, 22, 0, 0, 0, 8, 23, 0, 0, 0, 8, 24, 0, 0, 0, 9, 17, 0, 0, 0, 9, 25, 0, 0, 0, 10, 19, 0, 0, 0, 10, 26, 0, 0, 0, 11, 23, 0, 0, 0, 11, 27, 0, 0, 0, 12, 18, 0, 0, 0, 12, 25, 0, 0, 0, 13, 21, 0, 0, 0, 13, 28, 0, 0, 0, 14, 24, 0, 0, 0, 14, 27, 0, 0, 0, 15, 20, 0, 0, 0, 15, 26, 0, 0, 0, 16, 22, 0, 0, 0, 16, 28, 0, 0, 0, 17, 29, 0, 0, 0, 18, 30, 0, 0, 0, 19, 31, 0, 0, 0, 20, 30, 1, 0, 0, 21, 31, 0, 1, 0, 22, 29, 1, 1, 0, 23, 31, 0, 0, 1, 24, 29, 1, 0, 1, 25, 32, 0, 0, 0, 26, 32, 1, 0, 0, 27, 30, 1, 0, 1, 28, 32, 1, 1, 0, 29, 30, 0, 0, 0, 29, 31, -1, 0, 0, 29, 32, 0, 0, 0, 30, 31, -1, 0, 0, 30, 32, 0, 0, 0, 31, 32, 1, 0, 0) |
Spacegroup: Fd-3m
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
9.10377 | 9.10377 | 9.10377 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.10714 | 0.10714 | 0.14286 |
0.01786 | 0.01786 | 0.03571 |
Edge end points:
Spacegroup: Fd-3m
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
7.607 | 7.607 | 7.607 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.07852 | 0.07852 | 0.17148 |
0.0148 | 0.0148 | 0.07577 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc178 | 2*23 | (2,3,1) | {6,3} | {5.5.5.5.5.5}{5.5.5} |
