Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 12 |
Edges per primitive translational unit | 30 |
Transitivity (vertex,edge) | (2,7) |
Vertex degrees | {7,4} |
Vertex coordination sequence | [(7, 26, 63, 118, 191, 282, 391, 518, 663, 826), (4, 11, 29, 67, 128, 209, 307, 422, 555, 706)] |
Wells’ vertex symbol | [4^10.6^11, 4^4.6^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 4, 0, 1, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 3, 0, 0, 1, 2, 3, 0, 1, 1, 2, 4, -1, 1, 1, 2, 4, 0, 1, 1, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 4, -1, 1, 1, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 4, 11, 0, 0, 0, 4, 12, 0, 0, 0, 5, 7, 1, -1, -2, 5, 9, 0, 0, 0, 5, 12, 0, 0, 0, 6, 8, 1, -1, -2, 6, 10, 1, 0, 0, 6, 11, 0, 1, 0, 7, 10, 0, 0, 1, 7, 11, -1, 1, 1, 8, 9, 0, 1, 1, 8, 12, 0, 1, 1, 9, 11, 0, 0, -1, 10, 12, 0, 0, -1) |
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.89607 | 3.25922 | 2.89677 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.25 | 0.53947 | 0.25 |
0.08333 | 0.09211 | 0.41667 |
Edge end points:
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.09221 | 3.51133 | 2.01062 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.25 | 0.58666 | 0.25 |
0.24847 | 0.134 | 0.52524 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2401 | *222222 | (2,7,6) | {4,7} | {4.4.6.4}{6.4.4.4.4.4.4} |
