Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 16 |
Edges per primitive translational unit | 40 |
Transitivity (vertex,edge) | (4,4) |
Vertex degrees | {4,4,6,8} |
Vertex coordination sequence | [(4, 12, 40, 52, 98, 144, 204, 232, 384, 386), (4, 14, 30, 64, 94, 152, 192, 282, 316, 452), (6, 14, 30, 64, 106, 146, 200, 276, 338, 408), (8, 16, 36, 64, 126, 132, 220, 266, 368, 400)] |
Wells’ vertex symbol | [6^4.9^2, 3^2.4.6^2.7, 3^4.4^2.6^4.7^5, 3^8.4^8.5^8.6^4] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 1, 7, 0, 0, 0, 1, 8, 0, 0, 0, 1, 9, 0, 0, 0, 2, 3, 0, 0, 0, 2, 4, 0, 0, 0, 2, 10, 0, 0, 0, 2, 11, 0, 0, 0, 2, 12, 0, 0, 0, 3, 5, 0, 0, 0, 3, 13, 0, 0, 0, 4, 6, 0, 0, 0, 4, 13, 1, 0, 0, 5, 7, 0, 0, 0, 5, 10, 0, 1, 0, 5, 12, 0, 1, 0, 5, 14, 0, 0, 0, 6, 8, 0, 0, 0, 6, 10, 1, 1, 0, 6, 11, 1, 1, 0, 6, 15, 0, 0, 0, 7, 9, 0, 0, 0, 7, 13, 0, 0, 1, 8, 9, 0, 0, 0, 8, 13, 1, 0, 1, 9, 10, 0, 0, 1, 9, 14, 0, -1, 1, 9, 15, -1, -1, 1, 10, 11, 0, 0, 0, 10, 12, 0, 0, 0, 10, 14, 0, -1, 0, 10, 15, -1, -1, 0, 11, 16, 0, 0, 0, 12, 16, 1, 0, 0, 14, 16, 1, 1, -1, 15, 16, 1, 1, -1) |
Spacegroup: I41/amd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.90423 | 2.90423 | 6.04723 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.375 |
0.1875 | 0.5625 | 0.125 |
0 | 0 | 0 |
0 | 0.75 | 0.125 |
Edge end points:
Spacegroup: I41/amd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.82839 | 2.82839 | 5.65711 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.375 |
0.24999 | 0.50001 | 0.125 |
0 | 0 | 0 |
0 | 0.75 | 0.125 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1597 | *2244 | (4,4,2) | {4,4,6,8} | {8.8.8.8}{8.3.3.8}{8.3.3.8.3.3}{... |
