h-net: hqc1137
Topological data
| Orbifold symbol | *2223 |
| Transitivity (vertex, edge, ring) | (4,4,2) |
| Vertex degrees | {3,6,4,3} |
| 2D vertex symbol | {3.6.3}{3.6.6.3.6.6}{6.6.6.6}{6.6.6} |
| Vertex coordination sequence | [(3, 8, 12, 34, 40, 108, 130, 364, 424, 1182), (6, 8, 22, 28, 78, 92, 258, 300, 834, 976), (4, 14, 18, 50, 60, 168, 196, 546, 638, 1774), (3, 9, 30, 33, 93, 108, 297, 351, 978, 1143)] |
| Delaney-Dress Symbol | <1137.2:9:1 3 5 7 9,2 3 4 6 8 9,1 4 5 6 7 8 9:3 6,3 6 4 3> |
| Dual net | hqc933 |
Derived s-nets
s-nets with faithful topology
No items to display.s-nets with edge collapse
No items to display.Derived U-tilings
1 record listed.| Image | U-tiling name | PGD Subgroup | Transitivity (Vert,Edge,Face) | Vertex Degree | Vertex Symbol | P net | G net | D net |
|---|---|---|---|---|---|---|---|---|
 |
UQC4270 | *2223 | (4,4,2) | {3,6,4,3} | {3.6.3}{3.6.6.3.6.6}{6.6.6.6}{6.... | No s‑net | No s‑net | No s‑net |
