h-net: hqc1849
Topological data
| Orbifold symbol | *2223 |
| Transitivity (vertex, edge, ring) | (4,5,2) |
| Vertex degrees | {4,12,3,4} |
| 2D vertex symbol | {5.5.5.5}{5.3.3.5.5.3.3.5.5.3.3.5}{5.3.3}{3.3.3.3} |
| Vertex coordination sequence | [(4, 28, 48, 124, 248, 572, 1232, 2744, 6012, 13260), (12, 12, 66, 90, 282, 522, 1260, 2652, 5952, 12996), (3, 19, 18, 104, 130, 436, 766, 1928, 3954, 9024), (4, 18, 18, 104, 130, 436, 766, 1928, 3954, 9024)] |
| Delaney-Dress Symbol | <1849.2:11:1 3 5 7 9 11,2 4 5 8 11 10,1 2 3 6 7 8 9 10 11:5 3,4 12 3 4> |
| Dual net | hqc1704 |
Derived s-nets
s-nets with faithful topology
No items to display.s-nets with edge collapse
No items to display.Derived U-tilings
1 record listed.| Image | U-tiling name | PGD Subgroup | Transitivity (Vert,Edge,Face) | Vertex Degree | Vertex Symbol | P net | G net | D net |
|---|---|---|---|---|---|---|---|---|
 |
UQC5033 | *2223 | (4,5,2) | {4,12,3,4} | {5.5.5.5}{5.3.3.5.5.3.3.5.5.3.3.... | No s‑net | No s‑net | No s‑net |
