h-net: hqc940
Topological data
| Orbifold symbol | *2224 |
| Transitivity (vertex, edge, ring) | (2,4,4) |
| Vertex degrees | {6,3} |
| 2D vertex symbol | {4.4.6.3.6.4}{6.3.3} |
| Vertex coordination sequence | [(3, 8, 30, 72, 162, 372, 858, 1968, 4518, 10380), (6, 18, 42, 96, 222, 510, 1170, 2688, 6174, 14178)] |
| Delaney-Dress Symbol | <940.2:9:1 2 3 4 6 8 9,1 3 5 6 7 9,2 4 7 8 9:4 4 6 3,6 3> |
| Dual net | hqc1138 |
Derived s-nets
s-nets with faithful topology
No items to display.s-nets with edge collapse
No items to display.Derived U-tilings
2 records listed.| Image | U-tiling name | PGD Subgroup | Transitivity (Vert,Edge,Face) | Vertex Degree | Vertex Symbol | P net | G net | D net |
|---|---|---|---|---|---|---|---|---|
 |
UQC1468 | *2224 | (2,4,4) | {6,3} | {4.4.6.3.6.4}{6.3.3} | No s‑net | No s‑net | No s‑net |
 |
UQC1469 | *2224 | (2,4,4) | {6,3} | {4.4.6.3.6.4}{6.3.3} | No s‑net | No s‑net | No s‑net |
