Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 16 |
Edges per primitive translational unit | 44 |
Transitivity (vertex,edge) | (2,6) |
Vertex degrees | {7,4} |
Vertex coordination sequence | [(7, 25, 82, 220, 468, 882, 1470, 2257, 3224, 4395), (4, 9, 38, 120, 285, 594, 1066, 1726, 2579, 3622)] |
Wells’ vertex symbol | [3^3.4^5.6.7^5.8^6.9, 3^3.4^3] |
Systre key | (3, 1, 1, -1, 0, 0, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 2, -1, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 3, 0, -1, 0, 3, 4, 0, 0, 0, 3, 10, 0, 0, 1, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 4, 5, 0, 0, 0, 4, 11, 0, 0, 0, 5, 6, 0, 0, 0, 5, 13, 0, 0, 0, 6, 6, -1, 1, 1, 6, 7, 0, -1, 0, 6, 12, 0, 0, 0, 6, 13, 0, 0, 0, 7, 7, -1, 1, 1, 7, 8, 0, 0, 0, 7, 14, 0, 0, 0, 7, 15, 0, 0, 0, 8, 9, 0, 0, 0, 8, 15, 0, 0, 0, 9, 10, 0, 0, 0, 9, 16, 0, 0, 0, 10, 10, 0, -1, 0, 10, 14, 0, 0, 0, 10, 16, 0, 0, 0, 11, 12, 0, 0, 0, 11, 13, 0, 0, 0, 12, 12, 0, 0, -1, 12, 13, 0, 0, 0, 12, 14, 1, -1, 0, 14, 14, 0, 0, -1, 14, 15, 0, 0, 0, 14, 16, 0, 0, 0, 15, 16, 0, 0, 0) |
Spacegroup: I41/a
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.90787 | 3.90787 | 4.02322 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.15909 | 0.59375 |
0.02273 | 0.22727 | 0.625 |
Edge end points:
Spacegroup: I41/a
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.66052 | 1.66052 | 1.65308 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.14006 | 0.21134 | 0.37327 |
0.06443 | 0.11863 | 0.30249 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc1622 | *2244 | (2,5,5) | {7,4} | {4.8.3.3.3.8.4}{3.3.4.3} |
