Barycentric geometry maximising unit cell volume
|
Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 48 |
Transitivity (vertex,edge) | (3,6) |
Vertex degrees | {4,4,4} |
Vertex coordination sequence | [(4, 9, 19, 42, 78, 121, 157, 228, 320, 393), (4, 10, 22, 45, 75, 117, 167, 229, 305, 402), (4, 10, 22, 45, 75, 118, 167, 227, 307, 406)] |
Wells’ vertex symbol | [4^3.6^3, 4^2.6.8^3, 4^2.6.8^3] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 2, 3, 1, 0, 0, 2, 6, 0, 0, 0, 2, 7, 0, 0, 0, 3, 8, 0, 0, 0, 3, 9, 0, 0, 0, 4, 7, 0, 0, 0, 4, 10, 0, 0, 0, 4, 11, 0, 0, 0, 5, 9, 0, 0, 0, 5, 12, 0, 0, 0, 5, 13, 0, 0, 0, 6, 8, 1, 0, 0, 6, 14, 0, 0, 0, 6, 15, 0, 0, 0, 7, 11, 1, 0, 0, 7, 16, 0, 0, 0, 8, 15, 0, 1, 0, 8, 17, 0, 0, 0, 9, 13, 0, 0, 1, 9, 17, 0, 0, 0, 10, 14, 0, 1, -1, 10, 15, 0, 1, -1, 10, 18, 0, 0, 0, 11, 18, 0, 0, 0, 11, 19, 0, 0, 0, 12, 16, -1, -1, 0, 12, 19, 0, -1, 1, 12, 20, 0, 0, 0, 13, 16, -1, -1, 0, 13, 21, 0, 0, 0, 14, 18, 1, 0, 1, 14, 22, 0, 0, 0, 15, 23, 0, 0, 0, 16, 19, 1, 0, 0, 17, 21, 0, 0, 1, 17, 23, 0, 1, 0, 18, 24, 0, 0, 0, 19, 24, 0, 0, 0, 20, 22, -1, 0, -1, 20, 23, -1, 0, 0, 20, 24, 0, -1, 1, 21, 22, 0, 0, -1, 21, 23, 0, 0, 0, 22, 24, 1, 0, 1) |
Spacegroup: I41/a
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.16284 | 4.16284 | 4.26689 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.01923 | 0.15385 | 0.60714 |
0.28846 | 0.30769 | 0.09524 |
0.13462 | 0.07692 | 0.2619 |
Edge end points:
Spacegroup: I41/a
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.47811 | 3.47811 | 3.4363 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.2006 | 0.21745 | 0.62168 |
0.3671 | 0.27974 | 0.03525 |
0.19897 | 0.11496 | 0.20238 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc1949 | *2244 | (2,5,5) | {4,4} | {8.4.6.4}{6.4.4.4} |
