Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {6,4,4} |
Vertex coordination sequence | [(6, 20, 54, 136, 305, 599, 1077, 1794, 2766, 4026), (4, 10, 26, 70, 172, 373, 717, 1258, 2045, 3090), (4, 10, 26, 70, 173, 371, 713, 1265, 2046, 3098)] |
Wells’ vertex symbol | [4^6.6^6.8^3, 4^4.6^2, 4^4.6^2] |
Systre key | (3, 1, 1, -1, 0, 0, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 2, 2, -1, 0, 0, 2, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 5, -1, 0, 0, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 4, 4, 0, -1, 0, 4, 9, 0, 0, 0, 4, 11, 0, 0, 0, 4, 12, 0, 0, 0, 5, 12, 0, 0, 0, 5, 13, 0, 0, 0, 6, 6, 0, 0, -1, 6, 14, 0, 0, 0, 6, 15, 0, 0, 0, 6, 16, 0, 0, 0, 7, 8, 1, 0, 0, 7, 15, 0, 0, 0, 7, 17, 0, 0, 0, 8, 16, 0, 0, 0, 8, 18, 0, 0, 0, 9, 12, 0, 1, 0, 9, 19, 0, 0, 0, 10, 13, -1, 0, 0, 10, 14, -1, -1, 1, 10, 19, 0, 0, 0, 11, 11, 0, -1, 0, 11, 17, -1, -1, 1, 11, 18, 0, 0, 1, 11, 20, 0, 0, 0, 12, 21, 0, 0, 0, 13, 14, 0, -1, 0, 13, 21, 0, 0, 0, 14, 14, 0, 0, -1, 14, 22, 0, 0, 0, 15, 16, 0, 0, 1, 15, 23, 0, 0, 0, 16, 24, 0, 0, 0, 17, 18, 1, 0, 0, 17, 23, 0, 0, 0, 18, 24, 0, 0, 0, 19, 21, 0, 1, 0, 19, 22, -1, -1, 1, 20, 20, -1, -1, 1, 20, 22, 0, -1, 1, 20, 23, -1, -1, 1, 20, 24, 0, 0, 1, 21, 22, 0, -1, 0, 22, 22, -1, -1, 1, 23, 24, 0, 0, 1) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.00386 | 3.00386 | 3.15504 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.09146 | 0.21341 | 0.08036 |
0.5622 | 0.06951 | 0.0506 |
0.13049 | 0.0378 | 0.28274 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.86923 | 1.86923 | 1.86783 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.25591 | 0.01568 | 0.07248 |
0.21483 | 0.07506 | 0.0927 |
0.24561 | 0.5898 | 0.08178 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2297 | *22222 | (2,7,5) | {4,6} | {4.4.4.4}{4.4.4.4.4.4} |
