Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 36 |
Edges per primitive translational unit | 64 |
Transitivity (vertex,edge) | (3,5) |
Vertex degrees | {3,4,4} |
Vertex coordination sequence | [(3, 5, 10, 27, 38, 52, 91, 107, 140, 203), (4, 6, 16, 24, 41, 71, 83, 120, 171, 178), (4, 12, 12, 28, 54, 60, 100, 140, 136, 210)] |
Wells’ vertex symbol | [3.10^2, 3^2.4.10^2.11, 10^6] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 2, 3, 0, 0, 0, 2, 4, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 4, 8, 0, 0, 0, 5, 9, 0, 0, 0, 5, 10, 0, 0, 0, 5, 11, 0, 0, 0, 6, 12, 0, 0, 0, 6, 13, 0, 0, 0, 6, 14, 0, 0, 0, 7, 15, 0, 0, 0, 7, 16, 0, 0, 0, 8, 17, 0, 0, 0, 8, 18, 0, 0, 0, 9, 14, 1, 0, 0, 9, 19, 0, 0, 0, 9, 20, 0, 0, 0, 10, 13, 0, 1, 0, 10, 21, 0, 0, 0, 10, 22, 0, 0, 0, 11, 12, 0, 0, 1, 11, 23, 0, 0, 0, 11, 24, 0, 0, 0, 12, 23, 0, 0, -1, 12, 24, 0, 0, -1, 13, 21, 0, -1, 0, 13, 22, 0, -1, 0, 14, 19, -1, 0, 0, 14, 20, -1, 0, 0, 15, 16, 0, 0, 0, 15, 25, 0, 0, 0, 15, 26, 0, 0, 0, 16, 26, 0, 0, 0, 16, 27, 0, 0, 0, 17, 18, 0, 0, 0, 17, 27, 0, 1, -1, 17, 28, 0, 0, 0, 18, 25, -1, 1, 0, 18, 28, 0, 0, 0, 19, 29, 0, 0, 0, 20, 30, 0, 0, 0, 21, 26, 0, 1, -1, 22, 28, 1, 0, 0, 23, 31, 0, 0, 0, 24, 32, 0, 0, 0, 25, 33, 0, 0, 0, 25, 34, 0, 0, 0, 27, 35, 0, 0, 0, 27, 36, 0, 0, 0, 29, 33, 0, 1, -1, 29, 36, 1, 0, -1, 30, 34, 0, 0, 0, 30, 35, 1, 0, 0, 31, 33, 0, 1, 0, 31, 36, 1, 0, 0, 32, 34, -1, 1, 0, 32, 35, 0, 1, 0, 33, 36, 1, -1, 0, 34, 35, 1, 0, 0) |
Spacegroup: I41/acd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
6.56746 | 6.56746 | 7.36992 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.20833 | 0.375 | 0.0625 |
0.3 | 0.33333 | 0.025 |
0 | 0.25 | 0.375 |
Edge end points:
Spacegroup: I41/acd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.8867 | 4.8867 | 6.96248 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.19069 | 0.39474 | 0.0569 |
0.00125 | 0.08258 | 0.2924 |
0 | 0.25 | 0.375 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc778 | *2224 | (3,4,2) | {3,4,4} | {10.3.10}{10.10.3.3}{10.10.10.10} |
