Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 40 |
Edges per primitive translational unit | 72 |
Transitivity (vertex,edge) | (3,5) |
Vertex degrees | {6,3,3} |
Vertex coordination sequence | [(6, 14, 24, 42, 78, 139, 222, 333, 486, 696), (3, 8, 19, 37, 68, 111, 178, 276, 417, 607), (3, 8, 19, 37, 68, 112, 177, 283, 426, 612)] |
Wells’ vertex symbol | [4^4.6^4.8^4.10^3, 4.6.8, 4.6.8] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 7, -1, 0, 0, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 3, 11, 0, 0, 0, 4, 9, 0, 0, 0, 4, 12, 0, 0, 0, 5, 10, 0, 0, 0, 5, 13, 0, 0, 0, 6, 11, 1, 0, 0, 6, 14, 0, 0, 0, 7, 15, 0, 0, 0, 8, 16, 0, 0, 0, 8, 17, 0, 0, 0, 9, 18, 0, 0, 0, 10, 19, 0, 0, 0, 11, 20, 0, 0, 0, 12, 21, 0, 0, 0, 12, 22, 0, 0, 0, 13, 17, 0, 0, 0, 13, 23, 0, 0, 0, 14, 22, 0, 0, 0, 14, 24, 0, 0, 0, 15, 25, 0, 0, 0, 15, 26, 0, 0, 0, 16, 27, 0, 0, 0, 16, 28, 0, 0, 0, 17, 28, 0, 0, 0, 17, 28, 0, 1, 0, 17, 29, 0, 0, 0, 17, 30, 0, 0, 0, 18, 28, 0, 1, 1, 18, 30, 0, 0, 1, 19, 26, -1, 0, 0, 19, 31, 0, 0, 0, 20, 28, 0, 1, 1, 20, 29, 0, 1, 1, 21, 26, 0, 1, 1, 21, 32, 0, 0, 0, 22, 25, 0, 1, 0, 22, 26, 0, 1, 0, 22, 26, 0, 1, 1, 22, 31, 1, 1, 1, 23, 28, 0, 1, 0, 23, 33, 0, 0, 0, 24, 26, 0, 1, 0, 24, 34, 0, 0, 0, 25, 35, 0, 0, 0, 27, 35, 0, 0, 0, 27, 36, 0, 0, 0, 29, 37, 0, 0, 0, 30, 38, 0, 0, 0, 31, 39, 0, 0, 0, 32, 36, 1, 1, 1, 32, 38, 0, 0, 1, 33, 36, 0, 1, 0, 33, 39, 0, 0, 0, 34, 36, 1, 1, 0, 34, 37, 1, 1, 1, 35, 40, 0, 0, 0, 36, 40, -1, -1, -1, 36, 40, 0, 0, 0, 37, 40, 0, 0, -1, 38, 40, 0, 0, -1, 39, 40, -1, 0, -1) |
Spacegroup: I41/acd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.96748 | 4.96748 | 4.90104 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.13542 | 0.38542 | 0.125 |
0.37054 | 0.15923 | 0.20833 |
0.30506 | 0.30804 | 0.125 |
Edge end points:
Spacegroup: I41/acd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.58546 | 2.58546 | 2.49345 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.12501 | 0.37501 | 0.125 |
0.03513 | 0.25605 | 0.00609 |
0.15169 | 0.12876 | 0.30078 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1022 | *2224 | (2,4,3) | {3,6} | {8.4.6}{6.4.4.6.4.4} |
