s-net: sqc2597
 |
|
| Systre crystallographic geometry file (.cgd) |
Links to this net in other databases
| topcryst |
Topological data
| Vertices per primitive translational unit | 10 |
| Edges per primitive translational unit | 18 |
| Transitivity (vertex,edge) | (3,3) |
| Vertex degrees | {3,4,6} |
| Vertex coordination sequence | [(3, 7, 17, 39, 80, 137, 189, 277, 335, 460), (4, 14, 30, 64, 112, 158, 234, 286, 404, 450), (6, 18, 42, 78, 114, 182, 222, 330, 366, 522)] |
| Wells’ vertex symbol | [5^2.6, 5^4.8^2, 5^6.8^6.11^3] |
| Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 0, 1, 1, 3, 0, 0, 0, 1, 3, 0, 1, 0, 1, 4, 0, 0, 0, 1, 4, 1, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 4, 9, 0, 0, 0, 4, 10, 0, 0, 0, 5, 8, 0, 0, -1, 5, 9, 0, 0, 0, 6, 7, 0, 1, 0, 6, 10, 1, 0, -1, 7, 9, 1, 0, 0, 8, 10, 0, -1, 0) |
Geometric data
Systre equilibrium placement (barycentric embedding) maximising unit cell volume
Spacegroup: R-3m
Parameters:
| a | b | c | alpha | beta | gamma |
|---|---|---|---|---|---|
| 3.21542 | 3.21542 | 6.22643 | 90.0 | 90.0 | 120.0 |
Vertex positions:
| X-pos | Y-pos | Z-pos |
|---|---|---|
| 0 | 0.25 | 0 |
| 0 | 0.5 | 0 |
| 0 | 1 | 0.5 |
Edge end points:
Systre coordinates favouring equal edge-lengths
Spacegroup: R-3m
Parameters:
| a | b | c | alpha | beta | gamma |
|---|---|---|---|---|---|
| 3.79322 | 3.79322 | 0.81451 | 90.0 | 90.0 | 120.0 |
Vertex positions:
| X-pos | Y-pos | Z-pos |
|---|---|---|
| 0 | 0.25001 | 0 |
| 0 | 0.5 | 0 |
| 0 | 1 | 0.5 |
Edge end points:
Hyperbolic sources
h-nets with faithful topology
1 record listed.| Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
|---|---|---|---|---|---|
 |
hqc259 | *2626 | (3,3,2) | {3,4,6} | {6.10.10}{10.10.10.10}{10.10.10.... |
