s-net: sqc2598
 |
|
| Systre crystallographic geometry file (.cgd) |
Links to this net in other databases
| topcryst |
Topological data
| Vertices per primitive translational unit | 10 |
| Edges per primitive translational unit | 18 |
| Transitivity (vertex,edge) | (3,3) |
| Vertex degrees | {3,4,6} |
| Vertex coordination sequence | [(3, 7, 18, 44, 98, 179, 275, 391, 525, 681), (4, 14, 34, 78, 142, 238, 338, 474, 610, 790), (6, 18, 48, 90, 164, 242, 360, 474, 636, 786)] |
| Wells’ vertex symbol | [6^3, 6^2.8^4, 6^6.8^6.12^3] |
| Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 0, 1, 1, 3, 0, 0, 0, 1, 3, 0, 1, 1, 1, 4, 0, 0, 0, 1, 4, 2, 1, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 4, 9, 0, 0, 0, 4, 10, 0, 0, 0, 5, 7, -1, 0, 0, 5, 9, 1, 1, 0, 6, 8, 1, 1, 0, 6, 10, 1, 0, -1, 7, 10, 1, 0, -1, 8, 9, 1, 0, 0) |
Geometric data
Systre equilibrium placement (barycentric embedding) maximising unit cell volume
Spacegroup: R-3m
Parameters:
| a | b | c | alpha | beta | gamma |
|---|---|---|---|---|---|
| 4.34719 | 4.34719 | 2.97552 | 90.0 | 90.0 | 120.0 |
Vertex positions:
| X-pos | Y-pos | Z-pos |
|---|---|---|
| 0.08333 | 0.16667 | 0.46667 |
| 0 | 0.5 | 0 |
| 0 | 1 | 0 |
Edge end points:
Systre coordinates favouring equal edge-lengths
Spacegroup: R-3m
Parameters:
| a | b | c | alpha | beta | gamma |
|---|---|---|---|---|---|
| 2.99742 | 2.99742 | 1.65026 | 90.0 | 90.0 | 120.0 |
Vertex positions:
| X-pos | Y-pos | Z-pos |
|---|---|---|
| 0.10713 | 0.05356 | 0.20496 |
| 0 | 0.5 | 0 |
| 0 | 1 | 0 |
Edge end points:
Hyperbolic sources
h-nets with faithful topology
1 record listed.| Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
|---|---|---|---|---|---|
 |
hqc259 | *2626 | (3,3,2) | {3,4,6} | {6.10.10}{10.10.10.10}{10.10.10.... |
