Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 10 |
Edges per primitive translational unit | 24 |
Transitivity (vertex,edge) | (2,6) |
Vertex degrees | {8,4} |
Vertex coordination sequence | [(8, 32, 74, 126, 192, 292, 406, 512, 646, 826), (4, 12, 42, 102, 178, 258, 356, 486, 627, 763)] |
Wells’ vertex symbol | [3^2.4^4.5^5.6^7.7^10, 3.4^2.5^2.6] |
Systre key | (3, 1, 1, -1, 0, 0, 1, 2, 0, 0, 0, 1, 2, 0, 1, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 2, -1, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 5, 0, -1, 0, 3, 5, 0, 0, 0, 3, 8, 0, 0, 1, 4, 6, 0, -1, 0, 4, 6, 0, 0, 0, 4, 7, -1, 0, 1, 5, 10, 0, 0, 1, 6, 9, -1, 0, 1, 7, 9, 0, -1, 0, 7, 9, 0, 0, 0, 8, 10, 0, -1, 0, 8, 10, 0, 0, 0) |
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.98337 | 1.77827 | 6.77146 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.4 |
0.16667 | 0.05 | 0.3 |
Edge end points:
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.0013 | 1.9985 | 5.49225 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.49236 |
0.25711 | 4E-05 | 0.15898 |
Edge end points:
