Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 14 |
Edges per primitive translational unit | 26 |
Transitivity (vertex,edge) | (5,6) |
Vertex degrees | {4,3,4,4,4} |
Vertex coordination sequence | [(4, 12, 28, 50, 72, 104, 160, 216, 262, 318), (3, 7, 12, 26, 51, 85, 124, 167, 235, 297), (4, 8, 18, 35, 65, 101, 143, 197, 255, 327), (4, 6, 10, 18, 42, 78, 116, 156, 194, 276), (4, 8, 12, 28, 58, 94, 136, 180, 242, 316)] |
Wells’ vertex symbol | [8^5.12, 4^2.6, 4^2.6.8^2.10, 4^4.6^2, 4^4.6^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 3, 9, 0, 0, 0, 4, 7, 1, 1, 0, 4, 9, 0, 1, 0, 4, 10, 0, 0, 0, 5, 10, 0, 0, 1, 5, 11, 0, 0, 0, 5, 12, 0, 0, 0, 6, 8, 1, 2, 1, 6, 11, 1, 1, 0, 6, 12, 0, 1, 0, 7, 13, 0, 0, 0, 8, 13, 0, 0, 0, 8, 14, 0, 0, 0, 9, 14, 0, 0, 0, 10, 13, 1, 1, 0, 10, 14, 0, 1, 0, 11, 14, 0, 1, 1, 12, 13, 1, 1, 1) |
Spacegroup: Cmma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.90645 | 7.50439 | 4.71136 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0.61905 |
0.25 | 0 | 0.09524 |
0 | 0.5625 | 0.14286 |
0.25 | 0 | 0 |
0 | 0 | 0 |
Edge end points:
Spacegroup: Cmma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.4563 | 6.00451 | 2.95736 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.75 | 0.49989 |
0.25 | 0 | 0.64351 |
0 | 0.63043 | 0.23877 |
0.25 | 0 | 0 |
0 | 0 | 0 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc2238 | *22222 | (5,6,2) | {4,4,3,4,4} | {10.10.10.10}{10.4.4.10}{10.4.4}... |
