Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 16 |
Edges per primitive translational unit | 40 |
Transitivity (vertex,edge) | (4,5) |
Vertex degrees | {6,6,4,4} |
Vertex coordination sequence | [(6, 19, 48, 94, 170, 258, 390, 532, 722, 908), (6, 19, 46, 97, 168, 276, 396, 556, 718, 932), (4, 12, 34, 75, 134, 233, 344, 496, 666, 880), (4, 12, 32, 66, 132, 222, 350, 488, 662, 826)] |
Wells’ vertex symbol | [4^7.6^7.8, 4^7.6^6.8^2, 4^4.6^2, 4^4.6^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 5, 0, 0, 0, 3, 7, 1, 0, 0, 3, 9, 0, 0, 0, 4, 6, 1, 0, 0, 4, 8, 0, 0, 0, 4, 10, 0, 0, 0, 5, 11, 0, 0, 0, 5, 12, 0, 0, 0, 5, 13, 0, 0, 0, 5, 14, 0, 0, 0, 6, 12, 0, 1, 0, 6, 13, 1, 1, 0, 6, 14, 1, 1, 0, 6, 15, 0, 0, 0, 7, 11, 0, 0, 1, 7, 12, 1, 1, 1, 7, 13, 1, 1, 1, 7, 14, 0, 0, 0, 8, 12, 1, 1, 1, 8, 13, 1, 1, 0, 8, 14, 2, 1, 1, 8, 15, 2, 1, 1, 9, 13, 0, 0, 0, 9, 13, 2, 1, 1, 9, 15, 1, 0, 1, 10, 11, 2, 1, 1, 10, 14, 2, 1, 0, 10, 14, 2, 1, 1, 11, 16, 0, 0, 0, 12, 16, -1, -1, 0, 12, 16, 0, 0, 0, 15, 16, -1, 0, 0) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.00525 | 3.00525 | 3.44474 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.11765 | 0.88235 | 0 |
0 | 0 | 0.79167 |
0.35294 | 0.35294 | 0 |
0.25 | 0.07353 | 0.375 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.42453 | 2.42453 | 2.39734 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.8757 | 0.1243 | 0 |
0 | 0 | 0.37039 |
0.39239 | 0.39239 | 0 |
0.21746 | 0.75 | 0.125 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc136 | *2224 | (2,3,2) | {6,4} | {4.4.4.4.4.4}{4.4.4.4} |
