Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 44 |
Transitivity (vertex,edge) | (4,7) |
Vertex degrees | {3,4,4,4} |
Vertex coordination sequence | [(3, 8, 18, 39, 74, 124, 203, 306, 455, 636), (4, 10, 22, 48, 86, 147, 233, 351, 508, 699), (4, 12, 24, 52, 103, 167, 264, 388, 558, 751), (4, 12, 28, 60, 105, 165, 258, 384, 558, 759)] |
Wells’ vertex symbol | [5.6^2, 5^2.6^2.8.9, 5^4.8^2, 6^4.9.10] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 3, 9, 0, 0, 0, 4, 10, 0, 0, 0, 4, 11, 0, 0, 0, 4, 12, 0, 0, 0, 5, 7, -1, 0, 0, 5, 8, 0, 0, 0, 5, 13, 0, 0, 0, 6, 10, 0, 0, 0, 6, 11, -1, 0, 0, 6, 14, 0, 0, 0, 7, 15, 0, 0, 0, 8, 16, 0, 0, 0, 9, 14, 0, 0, 1, 9, 14, 0, 1, 0, 9, 17, 0, 0, 0, 10, 18, 0, 0, 0, 11, 19, 0, 0, 0, 12, 13, 1, -1, 0, 12, 13, 1, -1, 1, 12, 20, 0, 0, 0, 13, 21, 0, 0, 0, 14, 22, 0, 0, 0, 15, 20, 0, 1, -1, 15, 22, 0, 1, 0, 16, 20, -1, 1, 0, 16, 22, 0, 0, 1, 17, 18, 0, 0, 1, 17, 19, -1, 1, 0, 17, 23, 0, 0, 0, 18, 21, 1, -1, 0, 19, 21, 1, -1, 1, 20, 23, 0, -1, 0, 21, 24, 0, 0, 0, 22, 24, 0, -1, 0, 23, 24, 0, 0, 1, 23, 24, 1, -1, 1) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.08808 | 5.98713 | 5.37443 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.375 | 0.0625 | 0.14844 |
0 | 0.28409 | 0.04688 |
0.125 | 0.26136 | 0.125 |
0.125 | 0.125 | 0.48438 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.08788 | 3.39558 | 3.37656 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.30637 | 0.26131 | 0.18672 |
0.08523 | 0.06917 | 0.26646 |
0.125 | 0.05186 | 0.125 |
0.125 | 0.125 | 0.51544 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc1782 | *22222 | (4,6,2) | {3,4,4,4} | {6.5.6}{6.6.5.5}{5.5.5.5}{6.6.6.6} |
