Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {8,3,3} |
Vertex coordination sequence | [(8, 36, 129, 352, 762, 1431, 2383, 3627, 5164, 6991), (3, 8, 34, 128, 352, 762, 1431, 2383, 3627, 5164), (3, 8, 34, 128, 352, 762, 1431, 2383, 3627, 5164)] |
Wells’ vertex symbol | [4^10.6^14.8^4, 4^3, 4^3] |
Systre key | (3, 1, 1, -1, 0, 0, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 0, 1, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 2, -1, 0, 0, 2, 7, 0, 0, 0, 2, 7, 0, 0, 1, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 3, -1, -1, 0, 3, 9, 1, 0, 1, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 3, 13, 0, 0, 0, 4, 13, 0, 0, 0, 4, 14, 0, 0, 0, 5, 5, -1, 0, -1, 5, 7, 1, 1, 1, 5, 12, 0, 0, 0, 5, 12, 0, 1, 0, 5, 14, 0, 0, 0, 5, 15, 0, 0, 0, 6, 11, 0, 1, 0, 6, 15, 0, 0, 0, 7, 7, -1, 0, -1, 7, 16, 0, 0, 0, 7, 17, 0, 0, 0, 7, 18, 0, 0, 0, 8, 18, 0, 0, 0, 8, 19, 0, 0, 0, 9, 9, -1, -1, 0, 9, 17, 0, 0, 0, 9, 17, 0, 0, 1, 9, 19, 0, 0, 0, 9, 20, 0, 0, 0, 10, 16, 0, 0, 1, 10, 20, 0, 0, 0, 11, 21, 0, 0, 0, 12, 12, -1, -1, -1, 12, 17, 0, 0, 1, 12, 21, 0, 0, 0, 12, 22, 0, 0, 0, 13, 22, 0, 0, 0, 14, 22, 0, 0, 0, 15, 21, 0, 1, 0, 16, 23, 0, 0, 0, 17, 17, -1, -1, -1, 17, 23, 0, 0, 0, 17, 24, 0, 0, 0, 18, 24, 0, 0, 0, 19, 24, 0, 0, 0, 20, 23, 0, 0, 1) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.13439 | 3.13439 | 3.95452 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.03151 | 0.19958 | 0.09896 |
0.0105 | 0.10014 | 0.13021 |
0.0105 | 0.06653 | 0.11979 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.85588 | 1.85588 | 1.88849 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.11936 | 0.55006 | 0.07311 |
0.07532 | 0.60605 | 0.03975 |
0.23673 | 0.17711 | 0.22848 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2301 | *22222 | (2,7,5) | {8,3} | {4.4.4.4.4.4.4.4}{4.4.4} |
