Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {8,3,3} |
Vertex coordination sequence | [(8, 36, 104, 210, 348, 522, 732, 978, 1260, 1578), (3, 8, 34, 103, 210, 348, 522, 732, 978, 1260), (3, 8, 34, 103, 210, 348, 522, 732, 978, 1260)] |
Wells’ vertex symbol | [4^10.6^14.8^4, 4^3, 4^3] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 0, 1, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 4, 0, 1, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 7, -1, -1, 1, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 2, 10, 1, 0, 0, 3, 7, -1, -1, 1, 3, 7, -1, 0, 1, 3, 11, -1, -1, 1, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 3, 13, 0, 0, 0, 4, 10, 0, -1, 1, 4, 10, 1, 0, 0, 4, 11, 0, -1, 0, 4, 11, 0, -1, 1, 4, 14, 0, 0, 0, 4, 15, 0, 0, 0, 5, 13, 1, 0, 0, 5, 14, 0, 0, 0, 6, 8, 0, 0, 1, 6, 12, 1, 0, 0, 7, 16, 0, 0, 0, 7, 16, 0, 0, 1, 7, 17, 0, 0, 0, 7, 18, 0, 0, 0, 8, 17, 0, 0, 0, 9, 18, 0, 0, 0, 9, 19, 0, 0, 0, 10, 16, -1, -1, 1, 10, 16, -1, 0, 1, 10, 19, -1, 0, 0, 10, 20, 0, 0, 0, 11, 16, -1, 0, 1, 11, 16, 0, 0, 1, 11, 21, 0, 0, 0, 11, 22, 0, 0, 0, 12, 17, -1, 0, 1, 13, 21, -1, -1, 1, 14, 21, 0, -1, 1, 15, 20, 0, -1, 1, 15, 22, 0, -1, 1, 16, 23, 0, 0, 0, 16, 24, 0, 0, 0, 18, 23, 0, 0, 1, 19, 23, 0, 0, 1, 20, 24, -1, 0, 1, 22, 24, -1, 0, 1) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.79371 | 3.79371 | 3.72289 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.25151 | 0.03722 | 0.15625 |
0.2505 | 0.12173 | 0.30208 |
0.33602 | 0.17907 | 0.13542 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.32518 | 2.32518 | 2.327 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.25043 | 0.50003 | 0.1254 |
0.53419 | 0.06939 | 0.26037 |
0.11325 | 0.25114 | 0.05713 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2301 | *22222 | (2,7,5) | {8,3} | {4.4.4.4.4.4.4.4}{4.4.4} |
