Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {8,3,3} |
Vertex coordination sequence | [(8, 36, 114, 255, 457, 730, 1051, 1442, 1883, 2394), (3, 8, 34, 113, 255, 457, 730, 1051, 1442, 1883), (3, 8, 34, 113, 255, 457, 730, 1051, 1442, 1883)] |
Wells’ vertex symbol | [4^10.5^5.6^8.7^4.8, 4^3, 4^3] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 1, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 1, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 2, 11, 0, 0, 0, 2, 12, 0, 0, 0, 3, 4, 1, -1, 0, 3, 5, 0, 0, 1, 3, 12, 0, 0, 0, 3, 12, 0, 0, 1, 3, 12, 1, 0, 0, 3, 13, 0, 0, 0, 3, 14, 0, 0, 0, 4, 5, -1, 0, 1, 4, 11, 0, 0, 0, 4, 11, 0, 1, -1, 4, 11, 0, 1, 0, 4, 15, 0, 0, 0, 4, 16, 0, 0, 0, 5, 8, 0, 1, 0, 5, 8, 1, 0, 0, 5, 8, 1, 1, -1, 5, 17, 0, 0, 0, 5, 18, 0, 0, 0, 6, 9, 0, 1, 0, 6, 18, 0, 0, 0, 7, 10, 0, 1, 0, 7, 15, 0, 0, 0, 8, 11, 0, 0, -1, 8, 12, 0, -1, 0, 8, 19, 0, 0, 0, 8, 20, 0, 0, 0, 9, 20, 0, 0, 0, 10, 21, 0, 0, 0, 11, 12, -1, 0, 1, 11, 21, 0, 0, 0, 11, 22, 0, 0, 0, 12, 23, 0, 0, 0, 12, 24, 0, 0, 0, 13, 16, 1, -1, 0, 13, 23, 0, 0, 1, 14, 17, 0, 0, 1, 14, 24, 0, 0, 1, 15, 21, 0, 1, 0, 16, 22, 0, 1, 0, 17, 19, 0, 1, 0, 18, 20, 0, 1, 0, 19, 24, 0, -1, 0, 22, 23, -1, 0, 1) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.58961 | 3.58961 | 4.04312 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.11919 | 0.64286 | 0.01136 |
0.68729 | 0.1794 | 0.16288 |
0.25083 | 0.66985 | 0.00379 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.93513 | 1.93513 | 2.5634 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.24903 | 0.53644 | 0.27519 |
0.69178 | 0.18426 | 0.1557 |
0.30946 | 0.18393 | 0.01235 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc2301 | *22222 | (2,7,5) | {8,3} | {4.4.4.4.4.4.4.4}{4.4.4} |
