Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 24 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (3,8) |
Vertex degrees | {6,4,4} |
Vertex coordination sequence | [(6, 20, 50, 105, 189, 295, 419, 566, 734, 923), (4, 10, 25, 59, 117, 203, 315, 444, 594, 767), (4, 10, 25, 59, 118, 202, 314, 442, 592, 765)] |
Wells’ vertex symbol | [4^6.6^8.8, 4^4.6^2, 4^4.6^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 7, 0, 0, 0, 3, 7, 1, 0, 0, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 3, 13, 0, 0, 0, 4, 8, 1, 0, 0, 4, 14, 0, 0, 0, 4, 15, 0, 0, 0, 5, 10, 0, 0, 0, 5, 16, 0, 0, 0, 5, 17, 0, 0, 0, 6, 9, -1, 1, 1, 6, 9, 0, 1, 0, 6, 12, 0, 0, 1, 6, 15, 0, 0, 0, 6, 17, 0, 0, 0, 7, 18, 0, 0, 0, 7, 19, 0, 0, 0, 7, 20, 0, 0, 0, 8, 21, 0, 0, 0, 8, 22, 0, 0, 0, 9, 18, 0, 0, 1, 9, 21, 0, 0, 0, 9, 23, 0, 0, 0, 10, 23, 0, 0, 0, 10, 24, 0, 0, 0, 11, 19, 0, 0, 0, 11, 23, 1, 0, -1, 11, 24, 1, 0, -1, 12, 18, -1, 1, 1, 12, 18, 0, 1, 0, 12, 22, 0, 1, 0, 12, 24, 1, 0, -1, 13, 20, 1, 0, 0, 13, 21, 0, 1, 0, 13, 22, 0, 1, 0, 14, 18, 0, 0, 1, 14, 20, 0, 0, 1, 14, 22, 1, 0, 0, 15, 20, 0, 0, 1, 15, 21, -1, 1, 1, 16, 18, -1, 1, 1, 16, 19, -1, 1, 1, 16, 24, 0, 0, 0, 17, 19, -1, 1, 1, 17, 23, 0, 1, 0) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.95752 | 4.79968 | 5.94252 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.03125 | 0.325 | 0.04605 |
0.25625 | 0.025 | 0.14254 |
0.30625 | 0.175 | 0.02412 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.17683 | 2.60066 | 4.60891 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.31028 | 0.05874 | 0.05845 |
0.06996 | 0.15725 | 0.38026 |
0.08122 | 0.11881 | 0.265 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc2297 | *22222 | (2,7,5) | {4,6} | {4.4.4.4}{4.4.4.4.4.4} |
