Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 32 |
Edges per primitive translational unit | 56 |
Transitivity (vertex,edge) | (4,7) |
Vertex degrees | {3,3,4,4} |
Vertex coordination sequence | [(3, 6, 14, 29, 48, 71, 102, 137, 191, 251), (3, 6, 14, 29, 49, 71, 103, 145, 189, 240), (4, 9, 17, 30, 51, 82, 115, 151, 196, 246), (4, 9, 17, 30, 52, 80, 116, 155, 194, 244)] |
Wells’ vertex symbol | [4.8^2, 4.8^2, 4^2.6.8^2.10, 4^2.6.8^2.10] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 2, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 7, 0, 0, 0, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 4, 8, 0, 0, 0, 4, 9, 1, 0, 0, 4, 11, 0, 0, 0, 5, 12, 0, 0, 0, 5, 13, 0, 0, 0, 6, 14, 0, 0, 0, 6, 15, 0, 0, 0, 7, 16, 0, 0, 0, 7, 17, 0, 0, 0, 8, 17, 1, 0, 0, 8, 18, 0, 0, 0, 9, 15, 0, 1, 0, 9, 17, 0, 0, 0, 10, 18, 0, 1, 0, 10, 19, 0, 0, 0, 11, 16, 0, 0, 1, 11, 20, 0, 0, 0, 12, 21, 0, 0, 0, 12, 22, 0, 0, 0, 13, 17, 0, 0, 1, 13, 22, 0, 0, 0, 14, 23, 0, 0, 0, 14, 24, 0, 0, 0, 15, 24, 0, 0, 0, 16, 25, 0, 0, 0, 18, 26, 0, 0, 0, 19, 26, 0, 1, 0, 19, 27, 0, 0, 0, 20, 25, 0, 0, 1, 20, 28, 0, 0, 0, 21, 23, -1, 0, 1, 21, 27, 0, 0, 0, 21, 28, -1, -1, 0, 22, 29, 0, 0, 0, 23, 30, 0, 0, 0, 23, 31, 0, 0, 0, 24, 32, 0, 0, 0, 25, 31, 0, 0, 0, 26, 30, 0, 0, 1, 27, 31, -1, 0, 1, 27, 32, 0, 1, 1, 28, 30, 0, 1, 1, 28, 32, 1, 1, 0, 29, 30, -1, 0, 2, 29, 31, -1, -1, 1, 29, 32, 0, 0, 1) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
5.63113 | 7.04577 | 7.20806 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.09821 | 0.07589 | 0.33036 |
0.02679 | 0.11161 | 0.29464 |
0.45536 | 0.02232 | 0.09821 |
0.41964 | 0.08482 | 0.02679 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
5.74885 | 5.55478 | 5.49792 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.12812 | 0.07696 | 0.30115 |
0.29138 | 0.13659 | 0.28346 |
0.25859 | 0.2674 | 0.36078 |
0.03608 | 0.39265 | 0.01124 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc348 | *2224 | (2,4,3) | {4,3} | {4.8.8.4}{8.4.8} |
