s-net: sqc1469
















					Systre crystallographic geometry file (.cgd)











Links to this net in other databases





			topcryst










Topological data





Vertices per primitive translational unit 6


Edges per primitive translational unit 15


Transitivity (vertex,edge)(2,6)


Vertex degrees {4,7}


Vertex coordination sequence  [(4, 11, 31, 70, 126, 196, 278, 374, 485, 608), (7, 24, 56, 102, 160, 232, 319, 418, 529, 656)]


Wells’ vertex symbol [4^4.6^2, 4^12.6^9]


Systre key (3, 1, 1, -1, 0, 0, 1, 1, 0, -1, 0, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 2, -1, 0, 0, 2, 2, 0, -1, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 3, -1, 0, 0, 3, 6, 0, 0, 1, 4, 4, -1, 0, 0, 4, 5, 0, -1, 1, 5, 5, -1, 0, 0, 6, 6, -1, 0, 0)






Geometric data



Systre equilibrium placement (barycentric embedding) maximising unit cell volume





 Spacegroup: Cmmm



 Parameters:



 a   b   c   alpha   beta   gamma



			 1.57829
			 7.34625
			 0.94873
			 90.0
			 90.0
			 90.0








 Vertex positions:




				 X-pos
				 Y-pos
				 Z-pos





						 0.16667
						 0.2
						 0




						 0
						 0.1
						 0







Edge end points:











Systre coordinates favouring equal edge-lengths





 Spacegroup: Cmmm




 Parameters:



 a   b   c   alpha   beta   gamma



			 1.00041
			 7.79271
			 0.99998
			 90.0
			 90.0
			 90.0








Vertex positions:




					 X-pos
					 Y-pos
					 Z-pos





							 0.30701
							  0.18627
							  0




							 0
							  0.06415
							  0








Edge end points:















Hyperbolic sources





h-nets with faithful topology




		No items to display.




h-nets with edge collapse
