Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 8 |
Edges per primitive translational unit | 24 |
Transitivity (vertex,edge) | (2,6) |
Vertex degrees | {5,7} |
Vertex coordination sequence | [(5, 14, 47, 128, 229, 391, 528, 756, 957, 1275), (7, 26, 83, 168, 298, 440, 629, 830, 1089, 1348)] |
Wells’ vertex symbol | [3^3.4^4.5^3, 3^3.4^6.5^3.6^5.7^4] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 4, 0, 1, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 4, 0, 0, 0, 2, 6, 0, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 4, 0, 0, 1, 3, 5, -2, 0, -1, 3, 5, 0, -1, 1, 3, 6, 0, 0, 0, 3, 8, -1, 1, -1, 4, 5, -1, 0, -1, 4, 5, 0, -2, 1, 4, 7, 0, 0, 0, 5, 7, 0, 2, -1, 5, 8, 1, 1, 0, 6, 7, -1, 1, -1, 6, 8, -1, 1, -1, 7, 8, 1, -1, 1) |
Spacegroup: P4222
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.15346 | 2.15346 | 1.59162 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.08696 | 0 |
0.26087 | 0.73913 | 0.25 |
Edge end points:
Spacegroup: P4222
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.43077 | 1.43077 | 1.40424 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.3501 | 0 |
0.25185 | 0.74815 | 0.25 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1925 | *22222 | (2,6,5) | {7,5} | {4.4.3.3.3.4.4}{3.3.4.4.3} |
