Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 12 |
Edges per primitive translational unit | 30 |
Transitivity (vertex,edge) | (2,5) |
Vertex degrees | {7,4} |
Vertex coordination sequence | [(7, 18, 32, 55, 84, 117, 162, 210, 261, 324), (4, 12, 28, 47, 76, 116, 154, 202, 258, 314)] |
Wells’ vertex symbol | [3^2.4^6.5^4.6^7.7^2, 3^2.4^3.5] |
Systre key | (3, 1, 1, -1, 0, 0, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 2, -1, 0, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 2, 9, 0, 0, 0, 2, 10, 0, 0, 0, 3, 4, 0, 0, 0, 3, 4, 1, 0, 0, 3, 11, 0, 0, 0, 4, 11, 0, 0, 0, 5, 6, 0, 0, 0, 5, 6, 1, 0, 0, 5, 12, 0, 0, 0, 6, 12, 0, 0, 0, 7, 8, 0, 0, 0, 7, 8, 1, 0, 0, 7, 11, 0, 1, 0, 8, 11, 0, 1, 0, 9, 10, 0, 0, 0, 9, 10, 1, 0, 0, 9, 12, 0, 1, 0, 10, 12, 0, 1, 0, 11, 11, -1, 0, 0, 11, 12, 0, 0, 1, 12, 12, -1, 0, 0) |
Spacegroup: P4/mmm
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.90797 | 4.90797 | 1.34435 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.25 | 0 |
0.125 | 0.125 | 0.16667 |
Edge end points:
Spacegroup: P4/mmm
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.06293 | 4.06293 | 1.28254 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0.36502 | 0 |
0.18229 | 0.18229 | 0.25005 |
Edge end points:
