Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 16 |
Edges per primitive translational unit | 32 |
Transitivity (vertex,edge) | (6,8) |
Vertex degrees | {4,4,4,4,4,4} |
Vertex coordination sequence | [(4, 12, 24, 40, 62, 108, 164, 220, 296, 384), (4, 10, 20, 40, 78, 124, 174, 234, 310, 390), (4, 10, 22, 45, 83, 128, 181, 241, 314, 399), (4, 8, 16, 32, 64, 116, 170, 222, 290, 386), (4, 8, 16, 36, 68, 124, 174, 228, 300, 390), (4, 12, 32, 60, 92, 136, 196, 262, 332, 418)] |
Wells’ vertex symbol | [5^4.8^2, 4^2.5^2.6.7, 4^2.5.7^2.9, 4^4.6^2, 4^4.6^2, 7^4.10.11] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 2, 2, -1, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 3, 9, 0, 0, 0, 4, 8, 0, 0, 0, 4, 10, 0, 0, 0, 4, 11, 0, 0, 0, 5, 9, 0, 0, 0, 5, 10, -1, 0, 0, 5, 12, 0, 0, 0, 6, 13, 0, 0, 0, 6, 14, 0, 0, 0, 6, 15, 0, 0, 0, 7, 13, -1, 1, 0, 7, 14, 0, 1, 0, 7, 16, 0, 0, 0, 8, 14, 0, 1, 0, 8, 15, 0, 1, 0, 9, 13, -1, 1, 0, 9, 15, -1, 1, 0, 10, 15, 0, 1, 0, 10, 16, 0, 0, 1, 11, 12, 0, 0, 0, 11, 12, 1, 0, 0, 11, 14, 0, 0, 1, 12, 13, -1, 0, 1, 16, 16, -1, 0, 0) |
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.26906 | 1.93267 | 8.24786 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0 |
0.29167 | 0 | 0 |
0.33333 | 0.25 | 0.07143 |
0 | 0 | 0.5 |
0 | 0.25 | 0.46429 |
0.25 | 0.25 | 0.25 |
Edge end points:
Spacegroup: Imma
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
4.09449 | 1.11403 | 8.03342 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0 |
0.25002 | 0 | 0 |
0.25006 | 0.25 | 0.12259 |
0 | 0 | 0.5 |
0 | 0.75 | 0.62259 |
0.25 | 0.25 | 0.25 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc750 | *22222 | (3,5,2) | {4,4,4} | {4.4.4.4}{4.8.8.4}{8.8.8.8} |
