Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 20 |
Edges per primitive translational unit | 40 |
Transitivity (vertex,edge) | (4,6) |
Vertex degrees | {6,3,4,4} |
Vertex coordination sequence | [(6, 10, 22, 46, 122, 243, 442, 715, 1099, 1650), (3, 10, 19, 46, 97, 222, 390, 651, 1007, 1528), (4, 10, 32, 62, 136, 252, 434, 704, 1090, 1610), (4, 12, 32, 74, 146, 270, 448, 701, 1073, 1572)] |
Wells’ vertex symbol | [3^4.4^2.7^2.8^4.9^3, 3.7^2, 7^4.8.11, 7^4.8.10] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 3, 0, 0, 1, 2, 4, 0, 1, 0, 3, 5, 0, 0, 0, 3, 6, 0, 0, 0, 4, 7, 0, 0, 0, 4, 8, 0, 0, 0, 5, 9, -1, 0, -1, 5, 9, 0, 0, 0, 6, 10, 0, 0, -1, 6, 10, 0, 0, 0, 7, 11, 0, -1, 0, 7, 11, 0, 0, 0, 8, 12, -1, -1, 0, 8, 12, 0, 0, 0, 9, 9, -1, 0, -1, 9, 13, -1, 0, -1, 9, 13, 0, 0, 0, 10, 10, 0, 0, -1, 10, 14, 0, 0, -1, 10, 14, 0, 0, 0, 11, 11, 0, -1, 0, 11, 15, 0, -1, 0, 11, 15, 0, 0, 0, 12, 12, -1, -1, 0, 12, 16, -1, -1, 0, 12, 16, 0, 0, 0, 13, 17, 0, 0, 0, 14, 18, 0, 0, 0, 15, 18, 1, 1, 0, 16, 17, 0, 0, -1, 17, 19, 0, 0, 0, 17, 20, 0, 0, 0, 18, 19, -2, -1, 0, 18, 20, -1, -1, 0, 19, 20, 1, 0, 1, 19, 20, 1, 1, 0) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.44047 | 2.44047 | 2.6329 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.09375 | 0.90625 | 0 |
0.3125 | 0.125 | 0.29167 |
0.25 | 0.0625 | 0.375 |
0 | 0 | 0.79167 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
1.8013 | 1.8013 | 1.80093 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.12529 | 0.87471 | 0 |
0.32654 | 0.11994 | 0.20671 |
0.17612 | 0.75 | 0.125 |
0 | 0 | 0.0525 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1474 | *22222 | (4,5,2) | {6,3,4,4} | {3.7.3.3.7.3}{3.7.7}{7.7.7.7}{7.... |
