Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 20 |
Edges per primitive translational unit | 40 |
Transitivity (vertex,edge) | (4,6) |
Vertex degrees | {6,3,4,4} |
Vertex coordination sequence | [(6, 10, 22, 43, 96, 183, 318, 509, 728, 1043), (3, 10, 19, 42, 82, 174, 290, 476, 703, 999), (4, 10, 32, 59, 124, 224, 374, 577, 825, 1134), (4, 12, 32, 71, 140, 251, 400, 616, 858, 1186)] |
Wells’ vertex symbol | [3^4.4^2.7^2.8^5.9^2, 3.7^2, 7^4.8^2, 7^4.8.11] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 1, 0, 0, 1, 3, 0, 0, 0, 1, 4, 0, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 7, 0, 1, 0, 3, 8, 0, 0, 0, 4, 8, 0, 0, 1, 4, 9, 0, 0, 0, 4, 9, 0, 1, -1, 5, 10, 0, 0, 0, 5, 11, 0, 0, 0, 6, 12, 0, 0, 0, 6, 13, 0, 0, 0, 7, 14, 0, 0, 0, 7, 15, 0, 0, 0, 8, 16, -1, 0, 1, 8, 16, 0, 0, 0, 9, 17, 0, 0, 0, 9, 18, 0, 0, 0, 10, 11, 0, 0, 0, 10, 11, 1, -1, 0, 10, 14, 0, 0, 0, 10, 18, 0, 0, -1, 10, 19, 0, 0, 0, 11, 14, -1, 1, 0, 11, 18, 0, 0, -1, 11, 19, -1, 1, 0, 12, 13, -1, -1, 1, 12, 13, 0, 0, 0, 12, 15, -1, 0, 1, 12, 17, -1, 0, 0, 12, 20, 0, 0, 0, 13, 15, -1, 0, 1, 13, 17, 0, 1, -1, 13, 20, 1, 1, -1, 16, 19, 0, 1, -1, 16, 20, 2, 1, -2) |
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.09341 | 3.09341 | 4.3128 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0.125 |
0.19048 | 0.52381 | 0.33333 |
0.07143 | 0.92857 | 0 |
0.28571 | 0.28571 | 0 |
Edge end points:
Spacegroup: I4122
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.01562 | 2.01562 | 2.85117 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0.12372 |
0.25225 | 0.20096 | 0.15992 |
0.17191 | 0.82809 | 0 |
0.42274 | 0.42274 | 0 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1474 | *22222 | (4,5,2) | {6,3,4,4} | {3.7.3.3.7.3}{3.7.7}{7.7.7.7}{7.... |
