Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 12 |
Edges per primitive translational unit | 32 |
Transitivity (vertex,edge) | (2,5) |
Vertex degrees | {6,5} |
Vertex coordination sequence | [(6, 22, 53, 108, 191, 298, 424, 585, 753, 968), (5, 16, 48, 106, 191, 302, 438, 594, 782, 982)] |
Wells’ vertex symbol | [3^2.6^11.7.8, 3^2.4^2.5^2.6^2.7^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 2, 5, 0, 0, 0, 2, 5, 0, 1, 0, 2, 7, 0, 0, 0, 2, 8, 0, 0, 0, 3, 8, 0, 0, 1, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 3, 11, 0, 0, 0, 4, 6, -1, -1, -2, 4, 6, 0, 0, 0, 4, 7, 0, -1, -1, 4, 11, 0, -1, -1, 5, 7, 0, -1, 0, 5, 10, 0, -1, -1, 6, 7, 1, 0, 1, 6, 9, 1, 0, 1, 7, 12, 0, 0, 0, 7, 12, 1, 0, 0, 8, 10, 0, -1, -1, 8, 10, 0, 0, -1, 8, 12, 0, -1, -1, 9, 11, -1, -1, -2, 9, 11, 0, 0, 0, 9, 12, 0, -1, -1, 10, 12, 0, 0, 0, 11, 12, 1, 0, 1) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.76741 | 3.67744 | 3.0752 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.33333 | 0.125 | 0.125 |
0.16667 | 0.0625 | 0 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.08362 | 2.51476 | 1.80726 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.30293 | 0.125 | 0.125 |
0.23849 | 0.26366 | 0.27539 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc612 | *22222 | (2,4,3) | {5,6} | {4.3.6.3.4}{3.6.6.3.6.6} |
