Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 20 |
Edges per primitive translational unit | 32 |
Transitivity (vertex,edge) | (3,5) |
Vertex degrees | {4,3,3} |
Vertex coordination sequence | [(4, 10, 20, 36, 62, 88, 138, 186, 242, 328), (3, 6, 13, 26, 52, 84, 123, 172, 234, 311), (3, 5, 10, 25, 53, 78, 121, 174, 231, 316)] |
Wells’ vertex symbol | [10^2.11^4, 4.10^2, 4.11^2] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 3, 0, 0, 0, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 2, 5, 0, 0, 0, 2, 6, 0, 0, 0, 3, 7, 0, 0, 0, 3, 8, 0, 0, 0, 4, 9, 0, 0, 0, 4, 10, 0, 0, 0, 5, 10, 0, 1, 0, 5, 11, 0, 0, 0, 6, 9, 0, 0, 1, 6, 11, 0, 0, 0, 7, 12, 0, 0, 0, 7, 13, 0, 0, 0, 8, 14, 0, 0, 0, 8, 15, 0, 0, 0, 9, 16, 0, 0, 0, 10, 16, 0, 0, 0, 11, 17, 0, 0, 0, 12, 15, 0, 1, 0, 12, 18, 0, 0, 0, 13, 14, -1, 1, -1, 13, 18, 0, 0, 0, 14, 19, 0, 0, 0, 15, 19, 0, 0, 0, 16, 17, -1, 0, -1, 17, 20, 0, -1, 0, 17, 20, 0, 0, 0, 18, 20, -1, 0, -1, 19, 20, -1, -1, 0) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
5.11458 | 7.58461 | 4.89835 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0 |
0.08333 | 0.16667 | 0.375 |
0.0625 | 0.0625 | 0.4375 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.92121 | 9.6024 | 2.73496 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0 | 0 | 0 |
0.01991 | 0.35003 | 0.15062 |
0.01412 | 0.44974 | 0.04534 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
![]() |
hqc832 | *22222 | (3,4,2) | {4,3,3} | {12.12.12.12}{12.4.12}{12.12.4} |
