Systre crystallographic geometry file (.cgd) |
topcryst |
Vertices per primitive translational unit | 12 |
Edges per primitive translational unit | 36 |
Transitivity (vertex,edge) | (2,6) |
Vertex degrees | {10,4} |
Vertex coordination sequence | [(10, 47, 115, 216, 352, 515, 721, 944, 1214, 1505), (4, 18, 72, 155, 278, 420, 606, 824, 1070, 1352)] |
Wells’ vertex symbol | [3^2.4^12.5^20.6^9.7^2, 3^2.4^3.5] |
Systre key | (3, 1, 2, 0, 0, 0, 1, 2, 0, 1, 0, 1, 3, 0, 0, 0, 1, 3, 0, 0, 1, 1, 3, 0, 1, 1, 1, 3, 1, 0, 0, 1, 4, 0, 0, 0, 1, 5, 0, 0, 0, 1, 6, 0, 0, 0, 1, 7, 0, 0, 0, 2, 4, 1, -1, -1, 2, 5, 1, -1, -1, 2, 6, 0, -1, -1, 2, 7, 0, -1, -1, 2, 8, -1, 1, 1, 2, 8, 0, 0, 0, 2, 8, 0, 1, 0, 2, 8, 0, 1, 1, 3, 8, -1, 1, 0, 3, 8, 0, 1, 0, 3, 9, 0, 0, 0, 3, 10, 0, 0, 0, 3, 11, 0, 0, 0, 3, 12, 0, 0, 0, 4, 5, 0, 0, 0, 4, 10, 0, 0, 0, 5, 9, 0, 1, 1, 6, 7, 0, 0, 0, 6, 12, 1, 0, 0, 7, 11, 0, 0, 1, 8, 9, 1, -1, -1, 8, 10, 1, -1, -1, 8, 11, 1, -2, -1, 8, 12, 1, -2, -1, 9, 10, 0, 0, 0, 11, 12, 0, 0, 0) |
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
3.45183 | 3.4492 | 3.72547 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.125 | 0.375 | 0.125 |
0.04167 | 0.54167 | 0 |
Edge end points:
Spacegroup: Fddd
Parameters:
a | b | c | alpha | beta | gamma |
---|---|---|---|---|---|
2.41164 | 2.58168 | 2.46053 | 90.0 | 90.0 | 90.0 |
Vertex positions:
X-pos | Y-pos | Z-pos |
---|---|---|
0.125 | 0.03203 | 0.125 |
0.19775 | 0.30693 | 0.30863 |
Edge end points:
Image | h-net name | Orbifold symbol | Transitivity (Vert,Edge,Face) | Vertex Degree | 2D Vertex Symbol |
---|---|---|---|---|---|
hqc1038 | *22222 | (2,5,3) | {10,4} | {4.4.3.4.4.4.4.3.4.4}{4.4.3.3} |
